Ceramic Ball Valve

Pushing the boundaries of valve technology, ceramic ball valves feature ceramic components that offer exceptional resistance to corrosion, abrasion, and wear. The use of ceramics ensures longevity and reliability in harsh operating conditions where traditional materials may fail. These valves are ideal for handling abrasive or corrosive fluids in industries such as mining, chemical processing, and wastewater treatment. Their smooth and hard surfaces minimize friction and reduce the risk of contamination, making them suitable for critical applications where purity is paramount. With their superior performance and durability, ceramic ball valves provide a cost-effective solution for demanding environments..

Design advantages:

Exceptional Wear Resistance: Ceramic components withstand abrasion for extended service life.

Corrosion Resistance: Ideal for corrosive environments due to inert ceramic materials.

High-Temperature Performance: Maintains integrity under elevated temperatures.

Precise Flow Control: Smooth operation ensures accurate regulation of fluid flow.

Minimal Maintenance: Resilient to fouling, reducing downtime for cleaning.

Leakage Prevention: Superior sealing properties prevent fluid leakage.

Versatile Applications: Suitable for various industries including chemical processing and mining.

Technical Parameters:
SizeDN15-DN1500, 1/2''-60''
PressurePN10-PN420, Class150-Class2500
Temperature-200°C to 650°C
Connection typeFlange, Thread, Socket weld, Butt weld
Operation modeManual, Pneumatic, Electric, Hydraulic, Gear operation


Materials:
Valve Body

Forged: A105, LF2, F5, F9, F11, F22, F304, F316, F347, F904, F51, F53, F310, N08020, Inconel625, etc,

Cast: WCB, LCB, C5, C12, WC6, WC9, CF8, CF8M, CF8C, 4A, 5A, CN7M, C95800, CW6MC, etc

Valve Stem

F6a, 17-4PH, XM-19, F304, F316, F347, F904, F51, F53, F310, Monel400, Monel500, N08020, Inconel625, Incoloy825,etc

Valve Disc

A105, LF2, F5, F9, F11, F22, F304, F316, F347, F904, F51, F53, F310, N08020, Inconel625, F6a, 17-4PH, XM-19, F304, F316, F347, F904, F51, F53, F310, Monel400, Monel500,Incoloy825,WCB, LCB, C5, C12, WC6, WC9, CF8, CF8M, CF8C, 4A, 5A, CN7M, C95800, CW6MC, et

Seat SealingSS,BR,CU,AS,CS,AL,PTFE,NBR,FKM,AI203,etc


Design Standards:
Valve Body

API 6D, API 608, ASME B16.34, DIN 3357, BS 5351, GOST 9833, JIS B2071, GB/T 12237,etc.

Flange

ANSI B16.5, EN 1092-1, JIS B2220, GB/T 9113, ASME B16.47, GOST 12821, DIN 2543-2545,etc.

Connection

ANSI B16.10, ASME B16.25, JIS B2212, GOST 33259, DIN 3202,etc.


Test Standards:
API 598, ISO 5208, BS EN 12266, ASME B16.104, GOST 9544-2015, JIS B2003, DIN 3230, etc.

The meticulous selection of design standards for ceramic ball valves is vital for ensuring compliance with international quality and safety standards. Adhering to these standards guarantees exceptional performance, durability, and compatibility in diverse installations and applications.

Shen Gao's Comprehensive Range of
Ceramic Ball Valve
Discover the Ceramic Ball Valve Tailored to Your Needs.
Shen Gao Valves
Shen Gao Valves: 36 Years of Manufacturing Expertise, Delivering One-Stop Ball Valve Solutions.
A reputable provider offers more than just a product sale. Shengao provide strong post-purchase support, addressing issues or concerns.
  • 01
    Select Application Scenarios
    Before choosing different types of ball valves, please determine their main uses. Whether it is water treatment, petroleum or other industries, different application scenarios will directly affect valve selection.
  • 02
    Choose The Right Valve Type
    Ball valves come in many different types. Depending on factors such as flow control and pressure, choose the one that will perform best in your system.
  • 03
    Select Materials
    Diversified selection of materials. Choose different materials according to needs. We provide materials ranging from conventional carbon steel to stainless steel to alloy materials, covering basically all valve materials.
  • 04
    Verify Feasibility
    Discuss with engineers and ask experts to verify to confirm that the valve meets technical requirements. Provide professional advice and installation and maintenance guidance
  • 05
    Quality Control
    We have a strict quality inspection department. Every link needs to be inspected before entering the next link. We will never miss any link until the product is delivered safely.
  • 06
    After-sales Service
    24-hour online customer service, 2-year warranty or 18 months after installation, whichever comes first.
