V Port Ball Valve

Navigating Complex Flows: V Port Ball Valves for Precision Control in Pipelines

V port ball valves are designed for precise flow control and modulation, making them ideal for throttling applications. The V-shaped port allows for accurate adjustment of flow rates with minimal turbulence, ensuring smooth operation and enhanced control. With their versatile design and high-performance characteristics, V port ball valves are suitable for a variety of industrial processes requiring precise flow management.

Why Choose Us?

Shengao'sV Port Ball Valves

Shengao's V port ball valves offer precise flow control and exceptional performance for demanding applications. Here's why they're the top choice:

01

Precise Flow Regulation

The V port design allows for precise control of flow rates, making Shengao's valves ideal for applications that require accurate flow modulation.
02

High Cv Values

With optimized flow paths, these valves offer high Cv values, maximizing flow capacity and efficiency.
03

Versatile Applications

Shengao's V port ball valves are suitable for a wide range of applications, including throttling, mixing, and diverting fluids in various industries.
04

Durable Construction

Constructed from high-quality materials, Shengao's V port ball valves are durable and reliable, ensuring long-term performance in demanding environments.
05

Customizable Options

Shengao offers customizable options such as actuation and material selection to meet specific application requirements.
06

Technical Expertise

Shengao's team of technical experts provides support and guidance to ensure the proper selection and installation of V port ball valves for optimal performance.

Key Components of V Port Ball Valve

Valve Body

Manufactured from durable materials such as stainless steel, offering excellent corrosion resistance and structural integrity.
V Port Ball

Features a specially machined ball with a V-shaped port, allowing for precise control of flow rates and facilitating modulation.
Seats

Designed with wear-resistant materials, providing tight shut-off and preventing leakage even under high pressures.
High Pressure Rating

Capable of withstanding high pressures, making them suitable for demanding applications.
Actuator

Allows for precise control of the valve position, facilitating accurate flow regulation.
Seals

Utilize resilient materials such as PTFE or elastomers, ensuring a reliable seal and preventing fluid leakage.
Temperature Resistance

Designed to operate effectively across a wide range of temperatures, from cryogenic to high-temperature applications.

Advantages of V Port Ball Valve

01

Precise Flow Control

The V-shaped port design enables precise modulation of flow rates, allowing for accurate control over fluid flow, making V port ball valves ideal for applications requiring precise flow regulation.
02

High Flow Capacity

The streamlined flow path created by the V port design minimizes flow resistance, resulting in higher flow capacities compared to standard ball valves, maximizing throughput and efficiency in fluid handling systems.
03

Enhanced Control Range

The unique geometry of the V port ball valve allows for a wider range of flow control compared to traditional ball valves, providing greater flexibility in process control and optimization.
04

Excellent Sealing Performance

V port ball valves feature tight shut-off capabilities, ensuring reliable sealing and preventing leakage even at high pressures and temperatures, contributing to process safety and integrity.
05

Versatility

V port ball valves are suitable for a wide range of applications, including control and throttling applications in industries such as oil and gas, chemical processing, power generation, and water treatment, thanks to their versatile flow control capabilities.

Why Choose
V Port Ball Valve?

V port ball valves offer precise flow control, high flow capacity, enhanced control range, excellent sealing performance, versatility, and durability, making them the preferred choice for applications requiring accurate and efficient fluid control. Whether in critical process control applications or high-flow industrial processes, V port ball valves deliver superior performance and reliability, contributing to optimized process efficiency and productivity.

About Shengao V Port Ball Valve

Valve Body Type :	Ball
Valve Body Material :	Cast WCB carbon steel (general application), forged A105 carbon steel (general application), 304/316 stainless steel, alloy (corrosion resistance, extreme conditions), etc.
Valve Stem Material :	When the valve body material is ordinary carbon steel, the valve stem material is usually CR13 series martensitic stainless steel (American standard 410 and 420 stainless steel materials) or higher-grade austenitic stainless steel materials. When the valve body material is stainless steel, the valve stem material is usually austenitic stainless steel (American standard SS304, SS316) with a grade no lower than the valve body material and a higher grade corrosion-resistant alloy material (Hastelloy, Monel, Inconel alloy) etc.
Valve ball material :	The valve stem material is basically the same as the valve ball, plus carbon steel electroplating ENP anti-corrosion material, unless there are special requirements. The material of the ball is also ZrO2, AI2O3, SiC, Si3N4, etc.
Seat Material :	The hard-sealed metal valve seat and fixed soft-sealed valve seat support ring of the ball valve should be made of the same material as the ball.
Seat Sealing Surface Material :	The valve seat material is basically the same material as the ball, except for special requirements.
Pressure level :	Class 150-2500（ASME standards）or PN10~PN420
Actuator :	Manual handwheel, electric actuator, pneumatic actuator, hydraulic actuator
Temperature :	Depending on the material used, operation can occur within a temperature range of -50°C to +400°C, although specific materials may alter this range.
Size:	1/2'' to 60'' (DN 15-1500)
