Concentric Butterfly Valves

Precision Flow Control: Unveiling Concentric Butterfly Valves by Shengao

Shengao proudly introduces its innovative series of concentric butterfly valves, tailored meticulously for the rigorous demands of the oil & gas industry. Drawing from the principles of concentricity, these valves present a unified center where the shaft, disc, and valve body are aligned, leading to consistent and reliable sealing. Unlike offset configurations, Shengao's concentric design guarantees uniform pressure distribution, ensuring enhanced lifecycle and reduced maintenance needs. Accommodating diameters ranging from 3 to 24 inches (DN 80-600), these valves epitomize flexibility, adeptly handling tasks from hydrocarbon refinement to liquid cargo transfer. Meeting ASME 150 and 300 standards, each unit is bolstered with a resilient polymer liner. In terms of material selection, options span from the dependable carbon steel to the rust-resistant capabilities of 316 or duplex stainless steel. Shengao's relentless commitment to ensuring seamless operation and minimization of leakage positions them at the forefront of sophisticated valve technology.

Why Choose Us?

ShenGao's Concentric Butterfly Valve

When it comes to exceptional fluid control, Shengao emerges as a trusted brand in the industrial arena, especially renowned for its concentric butterfly valves. Here’s a dive into why Shengao's concentric butterfly valves are a prudent choice:

01

Inherent Simplicity

Shengao’s concentric butterfly valves, by design, align the disc, shaft, and valve body on the same axis. This symmetry ensures consistent and dependable sealing, proving invaluable in maintaining uniform pressure and minimizing wear.
02

Materials That Matter

Beyond the conventional carbon steel, Shengao also provides enhanced choices such as 316 stainless steel and duplex stainless steel, tailored for high resilience against corrosion in demanding scenarios.
03

Adaptability at Its Best

Be it water treatment facilities, HVAC systems, or general processing plants, the broad applicability of Shengao's concentric butterfly valves underscores their suitability for varied industrial applications.
04

Dedication to Excellence

Keeping with rigorous standards, Shengao crafts its valves in compliance with the ASME 150 and 300 benchmarks. With seating materials ranging from PTFE to UHMWPE, the brand focuses on accommodating diverse operational requisites.
05

Unwavering Client Support

Choosing Shengao isn’t just an equipment decision; it’s a partnership. The brand assures customers of steadfast service, ensuring guidance throughout the valve’s operational lifecycle.
06

第六点小标题填写

第六点内容

Key Components of Concentric Butterfly Valves

Valve Body

Defines the fluid's route.
Disc

Central regulator of fluid flow.
Stem

Rotates the disc in alignment with the body.
Retaining Ring

Anchors the disc to the stem.
Actuator

Drives the valve's movement.
Seat

Ensures tight sealing against leaks.
Seals

Counter internal fluid leaks.

Advantages of Concentric Butterfly Valve

01

Space-Efficient and Sturdy

Crafted to be compact, these valves are also resilient, capable of handling a wide range of pressures, making them apt for varied applications.
02

Economical Option

Their simple structure often results in cost savings, both in initial investment and in long-term maintenance.
03

Seamless Sealing Design

Concentric butterfly valves, due to their concentric stem alignment, ensure even sealing around the entire circumference, making them leak-resistant and reliable.
04

Ideal for Low-Pressure Scenarios

Concentric butterfly valves are particularly suited for low to moderate pressure systems, given their inherent design.
05

Stable Operational Lifespan

Their streamlined design, coupled with fewer moving parts, translates to lesser wear and tear, offering longevity in service.

Why Choose Concentric Butterfly Valves?

When addressing fluid control, it's not only about the task but also the efficiency and reliability with which it's done. Concentric butterfly valves embody this principle. With their centered design and consistent performance, they present advantages that distinguish them from other valve types. Their even sealing, long-lasting operation, and adaptability to various conditions underscore their engineering finesse. In domains where accuracy and dependability are key, the choice of concentric butterfly valves symbolizes a commitment to operational excellence and enduring quality.

About Shengao Concentric Butterfly Valve

Body Type :	Concentric
Body Materials :	Cast Iron (for general applications), 316 stainless steel, and brass (for specific corrosion resistance applications), etc.
Stem Material :	Typically constructed of brass or a material compatible with the body to ensure no galvanic corrosion occurs.
Seat Material :	EPDM (Ethylene Propylene Diene Monomer), NBR (Nitrile Butadiene Rubber), Neoprene
Disc Material :	Generally made of ductile iron, stainless steel, or bronze, with potential coatings based on specialized applications.
Bearings:	Frequently fabricated from bronze or nylon for durability and to ensure minimal friction during operation.
Pressure Ratings :	Class 125-1500 (based on ASME standards) Or PN6~PN100
Actuators :	Manual lever, gearbox, electric actuator, hydraulic actuator
Temperature :	Depends on materials used, but typically, EPDM seats can accommodate temperatures from -40°C to +135°C, with variations possible with specific materials.
Size:	Available from 1/2''-48'' (DN15-DN1200)
