Side Mounted Ball Valve

Accessible and Reliable: Side Mounted Ball Valves in Pipeline Operations

Side mounted ball valves offer enhanced reliability and ease of maintenance with their innovative design. The side entry construction allows for quick access to internal components, simplifying inspection and repair procedures. With their robust sealing and dependable performance, side mounted ball valves provide efficient fluid control solutions for various industrial applications.

Why Choose Us?

Shengao's Side Mounted Ball Valves

Shengao's side-mounted ball valves offer streamlined installation and maintenance efficiency, making them the preferred choice for industrial applications. Here's why:

01

Space-Saving Design

The side-mounted configuration of these ball valves optimizes space utilization, making them ideal for tight or crowded piping systems.
02

Quick Access

With convenient side access to internal components, maintenance and repair tasks can be performed swiftly, minimizing downtime and operational disruptions.
03

High Performance Sealing

Equipped with high-performance sealing materials and mechanisms, Shengao's side-mounted ball valves ensure reliable and leak-free operation, even in challenging conditions.
04

Durable Construction

Crafted from durable materials such as stainless steel and reinforced polymers, these valves offer long-term durability and resistance to corrosion and wear.
05

Versatile Applications

Suitable for a wide range of applications across industries such as oil and gas, chemical processing, and water treatment, Shengao's side-mounted ball valves offer versatility and adaptability.
06

Enhanced Safety Features

Incorporating advanced safety features such as locking devices and emergency shut-off options, these valves prioritize personnel safety and asset protection.

Key Components of Side Mounted Ball Valve

Valve Body

Fabricated from durable materials like stainless steel or carbon steel, providing robustness and corrosion resistance.
Ball

Positioned horizontally within the valve body, enabling smooth flow control and shut-off.
Stem

Utilizes corrosion-resistant materials, facilitating precise actuation and control of the valve.
Seats

Crafted from wear-resistant materials such as PTFE or metal, ensuring a tight seal and preventing leakage.
Actuator

Enables manual or automated operation, allowing for precise control of flow and shut-off.
Seals

Employ resilient materials like elastomers or PTFE, enhancing sealing performance and preventing fluid leakage.
Compact Design

Side-mounted configuration conserves space and facilitates installation in tight spaces or restricted environments.

Advantages of Side Mounted Ball Valve

01

Space Efficiency

Side mounted ball valves are designed to conserve space, making them ideal for installations with limited clearance or tight piping configurations. Their compact design allows for easy integration into crowded piping systems without sacrificing performance.
02

Accessibility

The side entry design of these valves facilitates convenient access to internal components, such as the ball and stem, for inspection, maintenance, and repair. This accessibility simplifies routine tasks and reduces downtime associated with valve servicing.
03

Low Operating Torque

Side mounted ball valves typically feature a reduced operating torque compared to other valve designs, thanks to their innovative ball and stem arrangements. This translates to smoother operation, reduced wear on valve components, and energy savings during actuation.
04

Versatile Applications

Side mounted ball valves are suitable for a wide range of applications across various industries, including chemical processing, oil and gas, water treatment, and power generation. Their versatility makes them well-suited for both general and specialized fluid control requirements.
05

Reliable Sealing Performance

Side mounted ball valves are equipped with high-performance sealing materials and designs, such as resilient seats or metal-to-metal seals, ensuring tight shut-off and reliable sealing even in demanding operating conditions.

Why Choose
Side Mounted Ball Valve？

Side mounted ball valves offer several advantages, including space efficiency, accessibility, low operating torque, versatile applications, reliable sealing performance, and corrosion resistance. These benefits make them a preferred choice for engineers and operators seeking compact, efficient, and reliable fluid control solutions for diverse industrial applications. Whether in chemical processing plants, oil refineries, wastewater treatment facilities, or power generation facilities, side mounted ball valves deliver exceptional performance and ensure safe and efficient operation of fluid systems.

About Shengao Side Mounted Ball Valve

Valve Body Type :	Ball
Valve Body Material :	Cast WCB carbon steel (general application), forged A105 carbon steel (general application), 304/316 stainless steel, alloy (corrosion resistance, extreme conditions), etc.
Valve Stem Material :	When the valve body material is ordinary carbon steel, the valve stem material is usually CR13 series martensitic stainless steel (American standard 410 and 420 stainless steel materials) or higher-grade austenitic stainless steel materials. When the valve body material is stainless steel, the valve stem material is usually austenitic stainless steel (American standard SS304, SS316) with a grade no lower than the valve body material and a higher grade corrosion-resistant alloy material (Hastelloy, Monel, Inconel alloy) etc.
Valve ball material :	The valve stem material is basically the same as the valve ball, plus carbon steel electroplating ENP anti-corrosion material, unless there are special requirements. The material of the ball is also ZrO2, AI2O3, SiC, Si3N4, etc.
Seat Material :	The hard-sealed metal valve seat and fixed soft-sealed valve seat support ring of the ball valve should be made of the same material as the ball.
Seat Sealing Surface Material :	The valve seat material is basically the same material as the ball, except for special requirements.
Pressure level :	Class 150-2500（ASME standards）or PN10~PN420
Actuator :	Manual handwheel, electric actuator, pneumatic actuator, hydraulic actuator
Temperature :	Depending on the material used, operation can occur within a temperature range of -50°C to +400°C, although specific materials may alter this range.
Size:	1/2'' to 60'' (DN 15-1500)
