Thin Type Ball Valve

Space Efficiency, Maximum Performance: The Evolution of Thin Type Ball Valves

Thin type ball valves are characterized by their compact size and lightweight construction, making them ideal for space-constrained installations. Despite their slim profile, these valves offer robust sealing and reliable performance. With options for various materials and configurations, thin type ball valves provide flexible solutions for applications where space is limited.

Why Choose Us?

Shengao's Thin Type Ball Valves

Shengao's thin type ball valves offer a space-saving solution without compromising performance. Here's why they're the ideal choice:

01

Compact Design

The thin type construction reduces the overall footprint of the valve, making it suitable for installations where space is limited.
02

Lightweight

Despite their compact size, Shengao's thin type ball valves are lightweight, facilitating easier handling and installation.
03

High Flow Capacity

These valves feature a full bore design, allowing for high flow capacity and minimal pressure drop, ensuring efficient fluid handling.
04

Versatile Applications

Suitable for a wide range of applications, including HVAC systems, water treatment, and industrial processes, Shengao's thin type ball valves offer versatility and reliability.
05

Durable Construction

Built to withstand demanding operating conditions, these valves are constructed from high-quality materials, ensuring long-term durability and performance.
06

Easy Maintenance

The simple design of Shengao's thin type ball valves facilitates easy maintenance and servicing, reducing downtime and operational costs.

Key Components of Thin Type Ball Valve

Valve Body

Manufactured from lightweight materials such as aluminum or PVC, providing easy installation and resistance to corrosion.
Thin Type Ball

Features a slim profile, allowing for compact valve design and efficient flow control.
Stem

Utilizes lightweight materials, facilitating smooth actuation and precise valve positioning.
Seats

Designed with durable materials such as PTFE or elastomers, ensuring a tight seal and preventing leakage.
Actuator

Enables manual or automated operation of the valve, allowing for precise flow control.
Seals

Utilize resilient materials like elastomers or PTFE, providing additional sealing to prevent fluid leakage.
Low Torque Operation

The thin type ball design reduces friction between the ball and seats, resulting in low torque requirements for valve actuation.

Advantages of Thin Type Ball Valve

01

Space-Saving Design

Thin type ball valves feature a compact and lightweight construction, making them ideal for applications with limited installation space or weight restrictions, while still delivering high-performance functionality.
02

Low Flow Resistance

The streamlined flow path and thin profile of the valve body minimize flow resistance, ensuring smooth fluid flow and efficient operation, thereby reducing energy consumption and enhancing system performance.
03

Quick Response Time

Thin type ball valves are engineered for rapid opening and closing, providing fast response times for precise flow control and shut-off, which is particularly beneficial in dynamic process environments requiring swift adjustments.
04

High Pressure Rating

Despite their slim design, thin type ball valves are designed to withstand high pressures, making them suitable for demanding applications where pressure containment is critical, ensuring reliable performance under challenging conditions.
05

Corrosion Resistance

Constructed from corrosion-resistant materials such as stainless steel or exotic alloys, thin type ball valves offer excellent resistance to chemical corrosion, ensuring long-term reliability and durability in aggressive fluid environments.

Why Choose
Thin Type Ball Valve?

Thin type ball valves offer a combination of space-saving design, low flow resistance, quick response time, high-pressure rating, corrosion resistance, and versatile application, making them an ideal choice for applications where space constraints, efficient fluid handling, and reliable performance are paramount. Whether in critical process control systems or general fluid handling applications, thin type ball valves deliver optimal performance and reliability, ensuring efficient and safe operation across diverse industrial sectors.

About Shengao Thin Type Ball Valve

Valve Body Type :	Ball
Valve Body Material :	Cast WCB carbon steel (general application), forged A105 carbon steel (general application), 304/316 stainless steel, alloy (corrosion resistance, extreme conditions), etc.
Valve Stem Material :	When the valve body material is ordinary carbon steel, the valve stem material is usually CR13 series martensitic stainless steel (American standard 410 and 420 stainless steel materials) or higher-grade austenitic stainless steel materials. When the valve body material is stainless steel, the valve stem material is usually austenitic stainless steel (American standard SS304, SS316) with a grade no lower than the valve body material and a higher grade corrosion-resistant alloy material (Hastelloy, Monel, Inconel alloy) etc.
Valve ball material :	The valve stem material is basically the same as the valve ball, plus carbon steel electroplating ENP anti-corrosion material, unless there are special requirements. The material of the ball is also ZrO2, AI2O3, SiC, Si3N4, etc.
Seat Material :	The hard-sealed metal valve seat and fixed soft-sealed valve seat support ring of the ball valve should be made of the same material as the ball.
Seat Sealing Surface Material :	The valve seat material is basically the same material as the ball, except for special requirements.
Pressure level :	Class 150-2500（ASME standards）or PN10~PN420
Actuator :	Manual handwheel, electric actuator, pneumatic actuator, hydraulic actuator
Temperature :	Depending on the material used, operation can occur within a temperature range of -50°C to +400°C, although specific materials may alter this range.
Size:	1/2'' to 60'' (DN 15-1500)
